GRINS::PrescribedMoleFractionsDirichletOldStyleBCFactory Class Reference

#include <prescribed_vector_value_dirichlet_old_style_bc_factory.h>

Inheritance diagram for GRINS::PrescribedMoleFractionsDirichletOldStyleBCFactory:

Collaboration diagram for GRINS::PrescribedMoleFractionsDirichletOldStyleBCFactory:

Public Member Functions
	PrescribedMoleFractionsDirichletOldStyleBCFactory (const std::string &bc_type_name)
Public Member Functions inherited from GRINS::PrescribedSpeciesDirichletOldStyleBCFactory
	PrescribedSpeciesDirichletOldStyleBCFactory (const std::string &bc_type_name)
Public Member Functions inherited from GRINS::PrescribedVectorValueDirichletOldStyleBCFactory
	PrescribedVectorValueDirichletOldStyleBCFactory (const std::string &bc_type_name)
	~PrescribedVectorValueDirichletOldStyleBCFactory ()
Public Member Functions inherited from GRINS::DirichletBCFactoryFunctionOldStyleBase< libMesh::FunctionBase< libMesh::Number > >
	DirichletBCFactoryFunctionOldStyleBase (const std::string &bc_type_name)
	~DirichletBCFactoryFunctionOldStyleBase ()
Public Member Functions inherited from GRINS::DirichletBCFactoryFunctionBase< libMesh::FunctionBase< libMesh::Number > >
	DirichletBCFactoryFunctionBase (const std::string &bc_type_name)
	~DirichletBCFactoryFunctionBase ()
Public Member Functions inherited from GRINS::DirichletBCFactoryAbstract
	DirichletBCFactoryAbstract (const std::string &bc_type_name)
	~DirichletBCFactoryAbstract ()
Public Member Functions inherited from GRINS::BCFactoryAbstract< libMesh::DirichletBoundary >
	BCFactoryAbstract (const std::string &bc_type_name)
	~BCFactoryAbstract ()
Public Member Functions inherited from GRINS::FactoryWithGetPot< libMesh::DirichletBoundary >
	FactoryWithGetPot (const std::string &name)
	~FactoryWithGetPot ()

Protected Member Functions
virtual void	add_funcs (const GetPot &input, MultiphysicsSystem &system, const std::string &input_string, const std::vector< std::string > &var_names, libMesh::CompositeFunction< libMesh::Number > &composite_func) const
template<typename ChemistryType >
void	convert_mole_fracs_and_add_to_func (const GetPot &input, const std::vector< libMesh::Number > &species_mole_fracs, const SpeciesMassFractionsFEVariables &species_fe_var, libMesh::CompositeFunction< libMesh::Number > &composite_func) const
Protected Member Functions inherited from GRINS::PrescribedSpeciesDirichletOldStyleBCFactory
virtual std::string	var_input_string ()
Protected Member Functions inherited from GRINS::PrescribedVectorValueDirichletOldStyleBCFactory
virtual libMesh::UniquePtr< libMesh::FunctionBase< libMesh::Number > >	build_func (const GetPot &input, MultiphysicsSystem &system, std::vector< std::string > &var_names, const std::string &section)
	Builds the FunctionBase object for boundary condition. More...
Protected Member Functions inherited from GRINS::DirichletBCFactoryFunctionOldStyleBase< libMesh::FunctionBase< libMesh::Number > >
virtual void	check_state () const
	Helper function. More...
virtual void	reset_state ()
	Helper function. More...
virtual const std::vector< std::string > &	get_var_names () const
	Helper function that can be overridded in subclasses. More...
Protected Member Functions inherited from GRINS::DirichletBCFactoryFunctionBase< libMesh::FunctionBase< libMesh::Number > >
libMesh::UniquePtr< libMesh::DirichletBoundary >	make_dirichlet_boundary (const std::set< BoundaryID > &bc_ids, const libMesh::System &system, libMesh::UniquePtr< libMesh::FunctionBase< libMesh::Number > > &func, const std::vector< VariableIndex > &var_indices)
	Dispatch, based on FunctionType, to the correct DirchletBoundary construction. More...
Protected Member Functions inherited from GRINS::DirichletBCFactoryAbstract
void	check_for_vars (const GetPot &input, const std::string &section, const std::vector< std::string > &var_names, std::set< std::string > *vars_found=NULL)
	Helper function. More...
Protected Member Functions inherited from GRINS::BCFactoryAbstract< libMesh::DirichletBoundary >
void	check_for_multiple_expressions (const GetPot &input, const std::string &section, const std::string &var_name) const
	Ensure that there is only one expression for the [Section/var_name] variable. More...
void	build_var_indices (const MultiphysicsSystem &system, const std::vector< std::string > &var_names, std::vector< VariableIndex > &var_indices) const

Additional Inherited Members
Static Public Member Functions inherited from GRINS::DirichletBCFactoryFunctionOldStyleBase< libMesh::FunctionBase< libMesh::Number > >
static void	set_value_var_old_style (const std::string &value_var)
	Input variable for parsing old style. More...
static void	set_value_index_old_style (unsigned int idx)
	Input variable index for parsing old style. More...
static void	set_var_names_old_style (const std::vector< std::string > &var_names)
Static Public Member Functions inherited from GRINS::BCFactoryAbstract< libMesh::DirichletBoundary >
static void	set_system (MultiphysicsSystem &system)
static void	set_bc_ids (const std::set< BoundaryID > &bc_ids)
	Boundary id for the current boundary condition section. More...
static void	set_fe_var (const FEVariablesBase &fe_var)
	Active variable for the current boundary condition. More...
static void	set_section (const std::string &section)
	Sets the current section of the input file. More...
static bool	have_bc_type (const std::string &bc_type)
Static Public Member Functions inherited from GRINS::FactoryWithGetPot< libMesh::DirichletBoundary >
static void	set_getpot (const GetPot &input)
Static Protected Attributes inherited from GRINS::DirichletBCFactoryFunctionOldStyleBase< libMesh::FunctionBase< libMesh::Number > >
static std::string	_value_var_old_style
static unsigned int	_value_idx_old_style
static const std::vector< std::string > *	_var_names_old_style
Static Protected Attributes inherited from GRINS::BCFactoryAbstract< libMesh::DirichletBoundary >
static MultiphysicsSystem *	_system
	We store only a raw pointer here because we can't make a copy. More...
static const std::set< BoundaryID > *	_bc_ids
	BoundaryID for constructing a particular boundary condition. More...
static const FEVariablesBase *	_fe_var
	The FEVariablesBase class associated with the boundary condition being built. More...
static std::string	_section
Static Protected Attributes inherited from GRINS::FactoryWithGetPot< libMesh::DirichletBoundary >
static const GetPot *	_input
	We store only a raw pointer here because we can't make a copy. More...

Detailed Description

Definition at line 109 of file prescribed_vector_value_dirichlet_old_style_bc_factory.h.

Constructor & Destructor Documentation

GRINS::PrescribedMoleFractionsDirichletOldStyleBCFactory::PrescribedMoleFractionsDirichletOldStyleBCFactory ( const std::string &  bc_type_name )

inline

Definition at line 113 of file prescribed_vector_value_dirichlet_old_style_bc_factory.h.

      : PrescribedSpeciesDirichletOldStyleBCFactory(bc_type_name)
    {}

Member Function Documentation

void GRINS::PrescribedMoleFractionsDirichletOldStyleBCFactory::add_funcs ( const GetPot &  input, MultiphysicsSystem &  system, const std::string &  input_string, const std::vector< std::string > &  var_names, libMesh::CompositeFunction< libMesh::Number > &  composite_func  ) const

protectedvirtual

Reimplemented from GRINS::PrescribedVectorValueDirichletOldStyleBCFactory.

Definition at line 93 of file prescribed_vector_value_dirichlet_old_style_bc_factory.C.

References GRINS::PhysicsFactoryHelper::parse_thermochemistry_model(), GRINS::PhysicsNaming::reacting_low_mach_navier_stokes(), and GRINS::VariablesParsing::species_mass_fractions_section().

  {
    const unsigned int n_vars = var_names.size();

    // Parse in all the species mole fracs that are in the input
    std::vector<libMesh::Number> species_mole_fracs(n_vars);
    libMesh::Number invalid_num = std::numeric_limits<libMesh::Number>::max();

    if( input.vector_variable_size(input_string) != n_vars )
      libmesh_error_msg("ERROR: Expected "+StringUtilities::T_to_string<unsigned int>(n_vars)+" components in "+input_string);

    for(unsigned int v = 0; v < n_vars; v++ )
      species_mole_fracs[v] = input(input_string,invalid_num,v);

    // Make sure mole fracs sum to 1
    libMesh::Number sum = 0.0;
    for(unsigned int v = 0; v < n_vars; v++ )
      sum += species_mole_fracs[v];

    libMesh::Number tol = std::numeric_limits<libMesh::Number>::epsilon()*10;
    if( std::abs(sum-1.0) > tol )
      libmesh_error_msg("ERROR: Mole fractions do not sum to 1! Found sum = "+StringUtilities::T_to_string<libMesh::Number>(sum));


    // To avoid compiler warnings without GRINS or Cantera
#if defined(GRINS_HAVE_ANTIOCH) || defined(GRINS_HAVE_CANTERA)
    // This only makes sense for SpeciesMassFractionsFEVariables in the
    // VariableWarehouse. This call will error out if it's not there.
    const SpeciesMassFractionsFEVariables& species_fe_var =
      GRINSPrivate::VariableWarehouse::get_variable_subclass<SpeciesMassFractionsFEVariables>
      (VariablesParsing::species_mass_fractions_section());
#endif

    std::string thermochem_lib;
    PhysicsFactoryHelper::parse_thermochemistry_model( input,
                                                       PhysicsNaming::reacting_low_mach_navier_stokes(),
                                                       thermochem_lib );

    if( thermochem_lib == "cantera" )
      {
#ifdef GRINS_HAVE_CANTERA
        this->convert_mole_fracs_and_add_to_func<CanteraMixture>(input,
                                                                 species_mole_fracs,
                                                                 species_fe_var,
                                                                 composite_func);
#else
        libmesh_error_msg("Error: Cantera not enabled in this configuration. Reconfigure using --with-cantera option.");
#endif
      }
    else if( thermochem_lib == "antioch" )
      {
#ifdef GRINS_HAVE_ANTIOCH
        this->convert_mole_fracs_and_add_to_func<AntiochChemistry>(input,
                                                                   species_mole_fracs,
                                                                   species_fe_var,
                                                                   composite_func);
#else
        libmesh_error_msg("Error: Antioch not enabled in this configuration. Reconfigure using --with-antioch option.");
#endif
      }
    else
      libmesh_error_msg("ERROR: Invalid thermochemistry library "+thermochem_lib+"!");
  }

template<typename ChemistryType >

template void GRINS::PrescribedMoleFractionsDirichletOldStyleBCFactory::convert_mole_fracs_and_add_to_func< AntiochChemistry > ( const GetPot &  input, const std::vector< libMesh::Number > &  species_mole_fracs, const SpeciesMassFractionsFEVariables &  species_fe_var, libMesh::CompositeFunction< libMesh::Number > &  composite_func  ) const

protected

Todo:

We should have a ChemsitryWarehouse or something to just grab this from one place instead of rebuilding.

Definition at line 171 of file prescribed_vector_value_dirichlet_old_style_bc_factory.C.

References GRINS::SpeciesMassFractionsFEVariables::material(), and GRINS::SpeciesMassFractionsFEVariables::species().

  {
    const std::string& material = species_fe_var.material();

    ChemistryType chem(input,material);

    const unsigned int n_vars = species_mole_fracs.size();
    // Compute M
    libMesh::Real M = 0.0;
    for( unsigned int s = 0; s < n_vars; s++ )
      M += species_mole_fracs[s]*chem.M(s);

    // Convert mole fractions to mass fractions and add to function
    for( unsigned int s = 0; s < n_vars; s++ )
      {
        libMesh::Number species_mass_fracs =species_mole_fracs[s]*chem.M(s)/M;

        std::vector<VariableIndex> var_idx(1,species_fe_var.species(s));

        libMesh::ConstFunction<libMesh::Number> const_func(species_mass_fracs);
        composite_func.attach_subfunction(const_func,var_idx);
      }
  }

---

The documentation for this class was generated from the following files:

• src/boundary_conditions/include/grins/prescribed_vector_value_dirichlet_old_style_bc_factory.h
• src/boundary_conditions/src/prescribed_vector_value_dirichlet_old_style_bc_factory.C
